SKU: PL-M88C-MAX

8ft x 8ft Air Lux MAX – 1780W Full Colour Inflatable Kit

Air Lux MAX is the most advanced evolution of the inflatable lighting system from Pheon Lux. Engineered for professionals who demand uncompromising output and precision, MAX redefines what portable soft lighting can achieve.

Description

Powered by a new generation of high-efficiency LED chips, Air Lux MAX delivers up to 95% more brightness than its predecessor, dramatically increasing punch while maintaining beautifully soft, even diffusion. Whether working on large-scale film sets, broadcast environments, or high-end commercial productions, MAX provides the output headroom required for modern cameras and demanding lighting scenarios.

The advanced RGBWW light engine now features CIE XY colour control, giving creators absolute precision in colour reproduction. Dial in exact chromaticity coordinates, match other fixtures seamlessly, or fine-tune white points beyond traditional CCT adjustments. With CRI and TLCI of 95+, Air Lux MAX ensures faithful skin tones and colour accuracy across the spectrum.

Creative flexibility remains at its core. Zonal control enables dynamic gradients, smooth colour transitions, and full pixel mapping capabilities, allowing you to craft immersive lighting effects with ease.

Designed with mobility and speed at its core, the Air Lux MAX tubes retain an ultra-light inflatable construction that makes transport, rigging, and repositioning effortless. The streamlined form factor keeps weight to a minimum without sacrificing durability, making them ideal for dynamic set environments and overhead mounting. With the integrated rapid-inflation pump, deployment is fast and efficient—allowing crews to go from pack-down to full output in minutes. Air Lux MAX tubes are built for agile workflows, delivering maximum performance with minimal setup time.

Control is seamless and versatile via onboard manual controls, wired or wireless DMX (CRMX), or the intuitive mobile app.

Air Lux MAX — higher output, greater precision, stronger build. The next generation of intelligent inflatable lighting.

• Full colour – RGBWW
• High colour rendering
• Improved output
• Deep low-end dimming
• Lightweight light head
• Superior build quality
• Serviceable LED and inflatable part
• On-board USB rechargeable air pump
• Built-in gels and lighting effects
• Wired and wireless DMX, WiFi connectivity, app control
• Multiple DMX zones
• V-lock battery operation

Light Source RGBWW
Beam Angle 210°
Inflation Time AC: 6 min 20 sec
CCT 2,700-10,000K adjustable
Colour Rendering CRI >95, TLCI 95
Wattage 1600W
Input Voltage AC 100-240V
DMX Control XLR 5-pin (in/out), Lumen Radio CRMX, Pheon Lux App, WiFi, 2.4G
DMX Zones 64
Dimming 0-100%
Light Head Size 2130 x 2130 x 180 mm
Light Head Weight 13.69 kg
Controller Size (L x W x H) 164 x 140 x 355 mm
Controller Weight 4.28 kg

Kit Includes:
1 Light head (LED mat and inflatable)
1 Controller
1 Light head mount
1 7m Header cable
1 Power cable
1 Rechargeable mini DC pump
1 AC power air pump
1 Eggcrate
1 Skirt
1 Velcro strap handle
1 USB charging cable
1 Safety bond
1 Kit Bag

2700K 3200K 4300K 5600K 6000K
1 m 11800 lux 11900 lux 12700 lux 13500 lux 13400 lux
3 m 3280 lux 3320 lux 3530 lux 3780 lux 3710 lux
5 m 1650 lux 1680 lux 1780 lux 1910 lux 1890 lux
